3121822 5-3
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-1. LIFT CYLINDER ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
LIFT CYLINDER ASSEMBLIES Ref.
1683808 PRIOR TO S/N 03620 Ref. A
1684142 S/N 03620 TO PRESENT Ref. G
1 Kit O-Ring 1
2 Kit Wiper 1
3 Kit Seal 1
4 Kit O-Ring 1
5 Kit Seal 1
6 Kit Ring, Wear 1
7 Not Used
8 Locknut Options: 1
7003246 Prior to S/N 03620
7023391 S/N 03620 to Present
9 Not Used
10 Barrel Options: 1
7019839 Prior to S/N 03620
Not Available S/N 03620 to Present
11 Rod Options: 1
7019838 Prior to S/N 03620
7023393 S/N 03620 to Present
12 Piston Options: 1
7019835 Prior to S/N 03620
7023392 S/N 03620 to Present
13 Head Options: 1
7019834 Prior to S/N 03620
7023394 S/N 03620 to Present
14 Spacer Options: 1
7019872 Prior to S/N 03620
Not Required S/N 03620 to Present
15 Poppet, Solenoid Valve (S/N 03620 to Present Only) 1
7024354 Poppet, Solenoid Valve - 20 Volt Coil
7012958 20 Volt Coil Only
7012998 Seal Kit
16 7023397 Spring (S/N 03620 to Present Only) 1
17 7023398 Control Valve (S/N 03620 to Present Only) 1
18 7023399 Knob-Red 1
— — — — — — — — — —
7019865 Seal Kit - 1683808 (Includes Items 1-6) 1
7023395 Seal Kit - 1684142 (Includes Items 1-6) 1
