JLG 15VPSP (3121822) Parts Manual - Manual (Page 39)

3121822 3-5
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
87 4070988 Shim, Slide Pad (S/N 03617 to Present) 2
88 4070989 Shim, Slide Pad (S/N 03617 to Present) 2
89 4070990 Shim, Slide Pad (S/N 03617 to Present) 2
90 4567749 Tube, Spacer (S/N 03617 to Present) 1
91 4567751 Tube, Spacer (S/N 03617 to Present) 1
92 4740007 Washer, Thrust (S/N 03617 to Present) 14
— — — — — — — — — —
Not Available Mast Kit (Not Available at Time of Printing) 1
1260355 CHAIN ASSEMBLY - #544 CHAIN Rev. C
101 0100062 Loctite #RC/640 (Not Shown) A/R
102 0561308 Block, Chain Anchor 2
103 0561336 Block, Chain Anchor 2
104 Use 1260355 Chain 11.8ft/3.6m
105 3422338 Pin, Groove 2
106 3422720 Pin, Groove 4
107 3450202 Pin, Cotter 8
108 3450304 Pin, Cotter 2
109 3571101 Plate, Chain Adjustment 1
110 4300129 Stud 2
111 4751500 Flatwasher 5/16” 2
1260356 CHAIN ASSEMBLY - #444 CHAIN Rev. C
201 0100062 Loctite #RC/640 (Not Shown) A/R
202 0561149 Block, Chain Anchor 2
203 0561408 Block, Chain Anchor 2
204 Use 1260356 Chain 11.8ft/3.6m
205 3422338 Pin, Groove 2
206 3422346 Pin, Groove 2
207 3422355 Pin, Groove 2
208 3450304 Pin, Cotter 2
209 3571103 Plate, Chain Adjustment 1
210 4300111 Stud 2
211 4751500 Flatwasher 5/16” 2
1260357 CHAIN ASSEMBLY - #444 CHAIN Rev. C
301 0100062 Loctite #RC/640 (Not Shown) A/R
302 0561149 Block, Chain Anchor 2
303 0561408 Block, Chain Anchor 2
304 Use 1260357 Chain 11.8ft/3.6m
305 3422338 Pin, Groove 2
306 3422346 Pin, Groove 2
307 3422355 Pin, Groove 2
308 3450304 Pin, Cotter 2
309 3571101 Plate, Chain Adjustment 1
310 4300111 Stud 2
FIGURE 3-1. MAST ASSEMBLY - 15VPSP (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
