SECTION 4 PLATFORM
FIGURE 4-6. CONSOLE BOX ASSEMBLY (GAS, DIESEL & DUAL FUEL MACHINES JANUARY 1993
TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX ASSEMBLY - PQ CONTROLLERS & Ref.
VICKERS VALVE
0860825 2WS Ref. B
0860826 4WS Ref. B
1 0860739 Box Weldment 1
2940052 Latch 2
2600132 Hinge (Top to Bottom) 1
2600105 Hinge (Access Door) 1
3531023 Plate, Backing 1
2 Decal/Lid Plate Options: A/R
3252224 Lid (International Symbols) (January 1993 to May
1994) 1
3252382 Lid (International Symbols) (May 1994 to Novem-
ber 1994) 1
3538392 Plate, Lid (November 1994 to Present) 1
1702402 Decal, Console (November 1994 to Present) 1
3 4420008 Tape, Insulation 6ft/2.5m
4 0100001 Adhesive A/R
5 1600141 Controller Assembly Options (Note: Refer to JLG
Manual 3120351 for more information): 3
7011907 Electric Assembly 3
6 2560112 Knob 3
7 4360199 Switch, Toggle 4
8 4360202 Switch, Toggle 4
9 4360200 Switch, Toggle 1
10 3790012 O-Ring 9
11 4060229 Shield 5
12 2920015 Lamp 2
2920029 Bulb 2
13 4360274 Switch, Push Button 2
14 4360289 Switch, Emergency Stop 1
7012611 Head, Mushroom 1
7012612 Boot 1
15 4360282 Block, Contact 1
16 0751006 Screw, Pan Head #10-24NC x 3/4” 21
17 4740120 Washer, Nylon 21
18 3300177 Nut, Tinnerman 21
19 4460386 Connector, Strain Relief 1
20 0960905 Bushing, Insulating 1
21 3300147 Nut, Conduit 1
22 4460052 Connector 1
23 0960239 Bushing, Insulating 1
24 3300047 Nut, Conduit 1
25 4360202 Switch, Toggle 1
26 3790012 O-Ring 1
27 4060229 Shield 1
28 0901796 Bracket 1
