1-4 3120824
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
118 3323003 Nut, Slotted 1 1/4”-12NF 2
119 3450609 Pin, Cotter 3/16” x 2 1/4” 2
120 3421340 Kingpin 2
121 0440162 Washer, Thrust 2
122 3431622 Pin, Clevis 1
123 3450608 Pin, Cotter 3/16” x 2" 1
124 4712600 Flatwasher 1" 1
125 0440091 Washer, Thrust 3
126 0642628 Bolt 1"-8NC x 3 1/2” 2
127 0560805 Block, Tie-Rod (Right Side) 1
128 3312602 Nut, Jam 1"-8NC 2
129 3300175 Locknut 1
130 0560804 Block, Tie-Rod (Left Side) 1
131 3300229 Nut, Jam (Left Hand Thread) 1
132 3323002 Nut, Jam 1 1/4”-12NF 1
133 2160003 Fitting, Grease - 45° 2
FIGURE 1-1. FRAME AND STEERING INSTALLATION - 5’-9”/1.75M 2WD FRAME (WITH SINGLE
ROD CYLINDER) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
