SECTION 3 BOOM
FIGURE 3-1. BOOM AND CYLINDERS INSTALLATION
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
1001133311
Ref
BOOM & CYLINDERS INSTALLATIONS
F
1
0100011
AR
Compound, Locking
2
0100019
AR
Compound, Locking
3
0701021
4
Bolt M10 x 65mm
4
0701224
2
Bolt M12 x 80mm
5
Not Used
6
0761012
2
Bolt M10 x 25mm
7
0761014
1
Bolt M10 x 30mm
8
0761015
1
Bolt M10 x 35mm
9
0762013
4
Bolt M20 x 40mm
10
0762418
4
Bolt M24 x 50mm
11
3291005
6
Locknut M10
12
3291205
2
Locknut M12
13
Not Used
14
3841143
4
Keeper, Pin
15
3841287
4
Keeper, Pin
16
3841356
4
Keeper, Pin
17
Not Used
18
4812000
8
Flatwasher M10
19
4812100
4
Flatwasher M12
20
8310666
1
Bolt M20 x 180mm
21
1001131748
1
Lift Cylinder Assembly - Main Boom (See CYLINDER SECTION
for Breakdown)
22
1001132163
1
Level (Platform Slave) Cylinder Assembly (See CYLINDER
SECTION for Breakdown)
23
1001132275
1
Platform Rotator Assembly (See PLATFORM ROTATOR
ASSEMBLY for Breakdown)
24
1001132375
1
Master Cylinder Assembly (See CYLINDER SECTION
Breakdown)
25
1001133196
1
Link, Tower
26
1001133247
1
Link, Timing
26A
0962297
2
Bushing
27
1001133538
1
Main Boom Assembly (See MAIN BOOM ASSEMBLY for
Breakdown)
28
1001115672
1
Boom, Tower
29
1001133926
4
Bearing
30
1001133927
6
Bearing
31
1001133928
2
Bearing
32
1001134314
2
Pin
33
1001134315
1
Pin
34
1001134316
1
Pin
35
1001134317
1
Pin
36
1001134318
1
Pin
37
1001134319
1
Pin
38
1001134320
1
Pin
39
1001134321
2
Pin
40
1001134323
1
Pin
41
1001134324
1
Pin
42
1001134325
1
Pin
