3121288 24RS 9-1
SECTION 9 RECOMMENDED SERVICE
PARTS STOCK
MODEL 24RS
The following list will service one machine (built to current production per date on the front cover) with emergency repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep service
parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
Part Number Description Qty./Machine
STANDARD PARTS
70002386 Coil (Figure 1-5 & 2-2) 1
70003545 Element, Filter (Figure 2-1) 1
70002231 Element, Filter (Figure 2-1) 1
70003788 Coil (Figure 2-2) 1
7012664 Element, Air Cleaner (Figure 2-6) 1
3740067 Coil (Figure 2-6) 1
7016331 Filter, Oil Element (Figure 2-6) 1
8320270 Filter, Fuel (Figure 2-6) 1
70003614 Element, Hydraulic Tank (Fig 2-8) 1
70003614 Breather, Hydraulic Tank (Fig 2-8) 1
4360328 Switch, Toggle (Figures 2-10 & 4-2) 1
4360475 Switch, Mushroom (Figures 2-10 & 4-2) 1
4360476 Contact, Switch Block (Figures 2-10 & 4-2) 1
4360469 Switch, Key (Figure 2-10) 1
2860030 Key, Replacement (Figure 2-10) 1
3740080 Relay (Figure 2-11) 1
70004071 Carrier Repair Section (Figure 3-2) 1
1001129555 Controller (Lift and Swing) (Figure 4-2) 1
1001118416 Controller (Drive and Steer) (Figure 4-2) 1
4360330 Switch, Toggle (Figure 4-2) 1
4360387 Switch, Push Button (Figure 4-2) 1
4360407 Control, Speed (Figure 4-2) 1
4360331 Switch, Toggle (Figure 4-2) 1
70003788 Coil (Figure 5-2) 1
260305 Fuse 5A (Figure 7-2) 2
70020199 Diode (Figure 7-2) 2
2400065 Fuse 30A (Figure 7-2) 2
2400064 Fuse 5A (Figure 7-2) 2
1001118282 Relay (Figure 7-2) 1
VARIABLE PARTS
7027795 Module, Engine Control (Figure 2-6) 1
70004066 Filter, Fuel-Water Separator (Figure 2-8) 1
4360514 Switch, Proximity (Figures 2-9 & 7-2) 1
1001137033 Switch, Limit (Figure 2-9) 1
1001120431 Module, Ground Control (Figure 2-11) 1
1001150772 Sensor, Proximity (Figure 3-2) 1
1001118412 Module, Platform Control (Figure 4-2) 1
