SECTION 5 - JLG CONTROL SYSTEM
3121133
– JLG Lift –
5-11
2/6
LEVELING JACK EXTEND VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the
leveling jack extend valve is short to ground.
6
LEVELING JACK EXTEND VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the
leveling jack extend valve is short to battery.
LEVELING JACK RETRACT VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the
leveling jack retract valve is open circuit.
LEVELING JACK RETRACT VALVE SHORT TO GROUND Reported by the I/O module and during system test when the
leveling jack retract valve is short to ground.
LEVELING JACK RETRACT VALVE SHORT TO BATTERY Reported by the I/O module and during system test when the
leveling jack retract valve is short to battery.
FRONT DECK EXTEND VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the
front deck extend valve is open circuit.
FRONT DECK EXTEND VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the
front deck extend valve is short to ground.
FRONT DECK EXTEND VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the
front deck extend valve is short to battery.
FRONT DECK RETRACT VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the
front deck retract valve is open circuit.
FRONT DECK RETRACT VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the
front deck retract valve is short to ground.
FRONT DECK RETRACT VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the
front deck retract valve is short to battery.
REAR DECK EXTEND VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the
rear deck extend valve is open circuit.
REAR DECK EXTEND VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the
rear deck extend valve is short to ground.
REAR DECK EXTEND VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the
rear deck extend valve is short to battery.
REAR DECK RETRACT VALVE OPEN CIRCUIT
Reported by the I/O module and during system test when the
rear deck retract valve is open circuit.
REAR DECK RETRACT VALVE SHORT TO GROUND
Reported by the I/O module and during system test when the
rear deck retract valve is short to ground.
REAR DECK RETRACT VALVE SHORT TO BATTERY
Reported by the I/O module and during system test when the
rear deck retract valve is short to battery.
Table 5-1. Fault Code Listing - Software P1.X
Fault Flash
Code
Communicated (Displayed on Analyzer) Fault
Description
Priority
