Section 9 - Specifications
9-4
31200359
Reach at Maximum Height ........................................................................ 2 ft (0,6 m)
Maximum Travel Speed.....................................................................18 mph (29 kph)
Towing Capacity
Off-Highway ...............................................................................5500 lb (2500 kg)
On-Highway ...........................................................................................0 lb (0 kg)
Maximum Travel Grade (boom in travel position)
Gradeability.....................................................................................................45%
Side Slope ...................................................................................................8.75%
Dimensions
Overall Height.................................................................................75.6 in (1920 mm)
Overall Width ..................................................................................71.5 in (1816 mm)
Track Width ....................................................................................58.5 in (1486 mm)
Wheelbase......................................................................................90.0 in (2286 mm)
Length at Front Wheels ................................................................129.9 in (3299 mm)
Overall Length (less Attachment) .................................................144.2 in (3663 mm)
Ground Clearance ............................................................................10.8 in (274 mm)
Outside Turning Radius ............................................................... 126.0 in (3200 mm)
Turning Radius at Forks .............................................................. 169.0 in (4293 mm)
Maximum Gross Vehicle Weight (no attachment) ........................13 340 lb (6050 kg)
Maximum Front Axle Weight (no attachment)
(boom level and fully retracted) .......................................................6696 lb (3037 kg)
Maximum Rear Axle Weight (no attachment)
(boom level and fully retracted) .......................................................6644 lb (3013 kg)
Maximum Ground Bearing Pressure
12.00 x 16.5
Air Filled ......................................................................148 lb/in² (10,4 kg/cm²)
Foam Filled .................................................................172 lb/in² (12,1 kg/cm²)
14.00 x 17.5
Air Filled ........................................................................125 lb/in² (8,8 kg/cm²)
Foam Filled .................................................................151 lb/in² (10,6 kg/cm²)
