Page 86

7-18
SECTION 7 ELECTRICAL
507H cont’d
4461205
1
0275770/0275775 Installations & 1001100344/
1001141970 Service Kits
507J
A/R
Receptacle, Replacement Options:
Not Available
0
0274556/0274802 Installations (Purchase Components
Locally)
4461197
1
0275772 Installations
4461200
1
0275773 Installations
4461250
1
0275771 Installations
4461203
1
0275769/0275774 Installations & 1001100343/
1001141971 Service Kits
4461206
1
0275770/0275775 Installations & 1001100344/
1001141970 Service Kits
507K
A/R
Hardware Options:
4190406
Screw M4 x 12mm
4010408
Screw M4 x 16mm
4010414
Screw M4 x 30mm
0760606
Screw M6 x 12mm
0760608
Screw M6 x 16mm
0760612
Screw M6 x 25mm
3290405
Locknut M4
3290605
Locknut M6
4811400
Flatwasher M4
4811700
Flatwasher M6
507L
A/R
Bracket, Receptacle Box Mounting Options:
Not Required
0
0274556, 0274802, 0275769, 0275770, 0275771
Installations
0903551
1
0275772, 0275773, 0275774, 0275775 Installations
507M
3380766
1
Shield, Circuit Breaker Mounting (Required Only on CE Spec
Installations Except 0274802 Installation)
507N
2902559
A/R
Circuit Breaker Kit
D
Ref.
Note: Required Only on CE Spec Installations Except
0274802 Installation
1
Breaker, Circuit Options:
240015
1
Prior to S/N A200006201
See Note
A/R
Breaker 16 Amp S/N A200006201 to S/N A200009455
(Note: Was p/n 2400093. Use qty 1 each of p/ns
1001109475 & 1001109482 as replacement)
1001109475
1
Breaker 16 Amp (S/N A200009455 to Present)
1001109482
1
Breaker 30 Amp (S/N A200009455 to Present)
240093
1
Breaker Box (Prior to S/N 6201)
0861880
1
Breaker Box (S/N A200006201 to S/N A2000009897)
250135
1
Terminal Block (Prior to S/N A200006201)
4460957
1
Terminal Block (S/N A200006201 to S/N A2000009897)
4460956
1
Barrier, Terminal Block (S/N A200006201 to Present Only)
507P
2
Connector, Strain Relief Options:
4460633
Prior to S/N A200006201
1001097150
S/N A200006201 to S/N A2000009897
507R
1060908
1000mm
Cable, Electrical - 12/3
507S
1001103742
1
Decal - AC to Platform
507T
1001103743
1
Decal - AC to Charger
FIGURE 7-3. ELECTRICAL CONNECTORS INSTALLATION (MACHINES WITH 1600346 DRIVE
MODULE) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
