JLG 1230ES Parts Manual User Manual
Page 84
7-16
SECTION 7 ELECTRICAL
507 cont’d
220V-50/60HZ (0274802, 0275769, 0275770, 0275771,
0275773, 0275774, 0275775 Installations) Options:
3252507
USA Built Machines Prior to S/N 0200194028, French
Built Machines Prior to S/N A200009503
1001103742
USA Built Machines S/N 0200194028 to Present, French
Built Machines S/N A200009503 to S/N A2000009897
507A
1
Harness, AC to Battery Charger (No Serviceable Parts)
ANSI/CSA/Japan Specs
1060688
French Built Machines Prior to S/N A200008736
1001098832
French Built Machines S/N A200008736 to S/N
A2000009897
1060688
USA Built Machines Prior to S/N 0200183666
1001098832
USA Built Machines S/N 0200183666 to S/N
0200189617
1001103257
USA Built Machines S/N 0200189617 to Present
ANSI Export/Australian/CE Specs
1060689
USA Built Machines Prior to S/N 0200194028, French
Built Machines Prior to S/N A200009503
1001103258
USA Built Machines S/N 0200194028 to Present, French
Built Machines S/N A200009503 to S/N A2000009897
507B
1321293
1
Clamp
507C
A/R
AC Receptacle Box Kit Options:
2902431
1
0274556 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507F & 507H)
Not Available
0
0274802 Installations (Purchase Components Locally)
0275216
1
0275772 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507G)
0275217
1
0275773 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507G)
0275454
1
0275771 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507G)
0275452
1
0275769 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507G)
Use 1001100343
1
0275774 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507F, 507H & 507J) (was p/n 0275218 &
1001141971)
0275453
1
0275770 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507G)
Use 1001100344
1
0275775 Installations Switch Box/Receptacle Kit (Includes
Items 507D-507F, 507H & 507J) (was p/n 0275219 &
1001141970)
507D
A/R
Box Options:
0861731
1
0274556, 0275769, 0275770, 0275771 Installations
Not Available
0
0274802 Installations (Purchase Components Locally)
0861781
1
0275772/0275773 Installations
See Note
1
0275774/0275775 Installations (Note: Was
p/n0861782 which is no longer available. Use p/n
1001100344 CEE 7 Side Ground Service Kit or p/n
1001100343 CEE 7 Post Ground Service Kit. Kits
includes Box p/n 1001141967 & items 507D, 507E,
507F, 507H, 507J.)
FIGURE 7-3. ELECTRICAL CONNECTORS INSTALLATION (MACHINES WITH 1600346 DRIVE
MODULE) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
