RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
31200360
G5-18A/2505
12-1
SECTION 12
RECOMMENDED SPARE PARTS
Part Number
Description
Qty./Machine
Boom
Boom Hose, Twin Line, (Tilt & Aux), (Mechanical Quick Coupler), (see Figure 8-8)
1
Boom Hose, Twin Line, (Tilt), (Hydraulic Quick Coupler), (see Figure 8-9)
1
Boom Hose, Twin Line, (Aux), (Hydraulic Quick Coupler), (see Figure 8-9)
1
Shim, 0.134, (see Section 2)
2
Shim, 0.0747, (see Section 2)
2
Shim, 0.0747, (see Section 2)
6
Shim, 0.0359, (see Section 2)
AR
Shim, 0.0359, (see Section 2)
AR
Wear Pad, 15.88, (see Section 2)
8
Wear Pad, 15.9, (see Section 2)
4
Wear Pad Spacer, 1.00, (see Section 2)
2
Engine
Fuel Cap Assy, (see Figure 1-2)
1
Air Filter Pre-cleaner, (see Figure 1-1)
1
Hydraulic Oil Filter Element, (see Figure 4-1)
1
Engine Oil Filler Cap, (see Figure 4-2)
1
Engine Oil Filler Cap Seal, (see Figure 4-2)
1
Pre-fuel Filter Assy, (see Figure 4-3)
1
Secondary Fuel Filter, (see Figure 4-3)
1
Engine Oil Dipstick, (see Figure 4-3)
1
Thermostat, (see Figure 4-3)
1
Engine Oil Filter, (see Figure 4-3)
1
Alternator, (see Figure 4-3)
1
1
Fan Belt, (see Figure 4-3)
1
Radiator Cap, (see Figure 4-4)
1
Air Filter Primary Element, (see Figure 4-5)
1
Air Filter Secondary Element, (see Figure 4-5)
1
Belt, Air Conditioning, (see Figure 6-8)
1
Drive Train
Breather, (see Section 5)
3
Plug, Front/Rear Hub, (see Section 5)
7
Plug, Front/Rear Hub Magnetic, (see Section 5)
3
Plug, Rear Hub, (see Section 5)
12
Hydraulic
Hydraulic Tank Cover Gasket, (see Figure 1-1)
1
Hydraulic Cap Assy, (see Figure 1-1)
1
Boom Joystick, (see Figure 7-1)
1
Boom Joystick Handle Assy, (see Figure 7-1)
1
Seal Kit, Comp. Cylinder, (see Figure 9-4)
1
Seal Kit, Extend/Retract Cylinder, (see Figure 9-2)
1
Seal Kit, Tilt Cylinder, (see Figure 9-3)
1
Seal Kit, Lift Cylinder, (see Figure 9-1)
1
