Page 18
G5-18A/2505
31200360
1-10
FRAME & ATTACHING PARTS
1001080090
Ref
BATTERY COVER INSTALLATION, (2505 Before S/N 0160042694,
G5-18A Before S/N 0160046397), (not available to order, see items 201 thru
203 for service)
D
1001133788
Ref
BATTERY COVER INSTALLATION, (2505 S/N 0160042694 & After,
G5-18A S/N 0160046397 & After), (not available to order, see items 201 thru
203 for service)
A
201
1001080163
Ref
BATTERY COVER, (Before S/N 0160037452),
(no longer available, use Kit K1 for replacement)
1001112694
1
BATTERY COVER, (2505 S/N 0160037452 thru 0160042693,
G5-18A S/N 0160037452 thru 0160046248)
1001133787
1
BATTERY COVER, (2505 S/N 0160042694 & After, G5-18A S/N 0160046397
& After)
202
1001081000
1
CAM LOCK LATCH
203
1001080644
1
CAM LATCH
1001080571
Ref
FUEL CAP INSTALLATION,
(not available to order, see items 301 thru 303 for service)
B
301
1001001422
1
NECK FILLER ADAPTER
302
1001080707
1
LOCKING CAP
303
0100093
AR
LOCTITE
®
30512
TM
, (apply to item 301)
0275779
Ref
WHEEL CHOCK INSTALLATION, (if equipped), (Germany),
(not available to order, see items 401 thru 405 for service)
C
401
806253
1
WEDGE
402
4811900
4
WASHER, 8mm
403
0760806
4
HEX HD CAPSCREW, M8X12, GR8.8
404
1060628
1
CABLE TIE DOWN
405
806264
1
WEDGE HOLDER
501
Ref
CAB ASSY, (see Figure 6-1 for details)
502
Ref
ROAD LIGHT INSTALLATION, (see Figure 10-2 for details)
601
80363195
1
MIRROR, (G5-18A)
602
1001148177
1
RECTANGULAR MIRROR, (2505)
603
1001008436
1
MIRROR, (2505), (includes items 604 thru 606)
B
604
1001008475
2
LOCKWASHER, #12
605
1001009062
2
WASHER
606
1001010838
2
HEX HD BOLT
0275778
Ref
LIFT CYLINDER PROP INSTALLATION, (2505),
(not available to order, see items 701 thru 704 for service)
B
701
909304
AR
PROFILE RUBBER, 18X5mm
702
1271599
1
LIFT CYLINDER PROP WELDMENT
703
1784861
2
O-RING
704
1001099887
2
SCREW, M12X103
853
Ref
LICENSE PLATE LIGHT, (see Figure 10-2 for details)
1001104784
Ref
REAR CONVEX MIRROR INSTALLATION,
(not available to order, see items 901 thru 904 for service)
A
1001112236
Ref
REAR CONVEX MIRROR INSTALLATION, (2505 - AUS),
(not available to order see items 901 thru 904 for service)
B
901
4712200
2
WASHER, 3/4
Figure 1-2 Frame Covers, Shrouding & Attaching Parts (Continued)
Item
Part Number
Qty.
Description
Rev.
