SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121205 – JLG Lift – 6-3
Table 6-2. Operating Specifications - S/N 0300099060 to
Present
Maximum Work Load (Capacity)
ANSI
Unrestricted:
Restricted:
500 lb (227 kg)
1000 lb (454 kg)
Maximum Work Load (Capacity)
CE & Australia
Unrestricted:
Restricted:
500 lb (230 kg)
1000 lb (450 kg)
Maximum Travel Grade (Gradeability)
2WD
4WD
30%
45%
Maximum Travel Grade (Side Slope) 5°
Turning Radius (outside)
2WS/2WD
2WS/4WD
4WS/2WD
4WS/4WD
17 ft. 9 in. (5.41 m)
20 ft. 4.6875 in. (6.21 m)
11 ft. 4 in. (3.45 m)
11 ft. 2.6875 in. (3.42 m)
Turning Radius - (inside)
2WS/2WD
2WS/4WD
4WS/2WD
4WS/4WD
12 ft. (3.66 m)
14 ft. 3.875 in. (5.25 m)
5 ft. 5 in. (1.65 m)
5 ft. 3.625 in. (1.22 m)
Maximum Tire Load:
600S & 600SJ
660SJ
11,800 lbs. (5352 kg)
14,200 lbs. (6441 kg)
Ground Bearing Pressure
600S
600SJ
660SJ
67 psi (4.7 kg/cm 2 )
70 psi (4.9 kg/cm 2 )
75 psi (5.3 kg/cm 2 )
Maximum Drive Speed
2WD
4WD
4.5 MPH (7.25 Km/hr.)
4 MPH (6.44 Km/hr.)
Gross Machine Weight (Approximate)
600S - 2WD
600SJ - 2WD
660SJ - 2WD
600S - 4WD
600SJ - 4WD
660SJ) - 4WD
22,000 lbs. (9,979.2 kg)
23,500 lbs. (10,660 kg)
25,500 lbs. (11,567 kg)
22,510 lbs. (10,211 kg)
23,980 lbs. (10,877 kg)
25,910 lbs. (11,753 kg)
Table 6-2. Operating Specifications - S/N 0300099060 to
Present
