RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
31200454
G10-55A/G12-55A AccuPlace
12-1
SECTION 12
RECOMMENDED SPARE PARTS
Part Number
Description
Qty./Machine
Boom
Tilt Cylinder Hose, (see Figure 8-6)
1
Tilt Cylinder Hose, (see Figure 8-6)
1
Boom Hose, (see Figure 8-6)
2
Extend Chain, (G10-55A AccuPlace), (see Section 2)
4
Extend Chain, (G12-55A AccuPlace), (see Section 2)
4
Retract Chain, Third Section, (G10-55A AccuPlace), (see Figure 2-5)
1
Retract Chain, Third Section, (G12-55A AccuPlace), (see Figure 2-5)
1
Wear Pad, (see Section 2)
12
Wear Pad, (see Section 2)
6
Wear Pad, (G10-55A AccuPlace), (see Section 2)
6
Wear Pad, (G12-55A AccuPlace), (see Section 2)
4
Wear Pad, (G10-55A AccuPlace), (see Section 2)
12
Wear Pad, (G12-55A AccuPlace), (see Section 2)
10
Wear Pad, (see Section 2)
6
Wear Pad, (see Section 2)
2
Shim, .0598, (see Section 2)
AR
Shim, .0598, (see Section 2)
AR
Shim, .0598, (see Section 2)
AR
Shim, .0598, (see Section 2)
AR
Spacer, .060, (see Section 2)
24
Spacer, .060, (see Section 2)
4
Spacer, .0598, (see Section 2)
2
Spacer, .060, (see Section 2)
12
Quick Release Pin
1
Quick Switch Lock Pin
1
Engine
Primary Fuel Filter, (see Figure 4-1)
1
Secondary Fuel Filter, (see Figure 4-2)
1
Oil Filter, (see Figure 4-2)
1
Primary Air Filter, (G10-55A AccuPlace), (see Figure 4-5)
1
Primary Air Filter, (G12-55A AccuPlace), (see Figure 4-5)
1
Secondary Air Filter, (G10-55a AccuPlace), (see Figure 4-5)
1
Secondary Air Filter, (G12-55a AccuPlace), (see Figure 4-5)
1
Fuel Tank Cap, (see Figure 4-3)
1
1
Alternator Belt, (see Figure 4-2)
1
Dipstick, (see Figure 4-2)
1
Drivetrain
F-N-R Shifter, (see Figure 7-2)
1
Transmission Filter, (see Figure 4-19)
1
Universal Joint Kit, (see Figure 5-11
1
Universal Joint Kit, (see Figure 5-11
1
91403193
Lug Nut, (see Figure 5-12)
10
