3121842 800S 860SJ 7-45
SECTION 7 ELECTRICAL
708A cont’d See Note 1001091971, 1001100328, 1001091972, 1001100329
Installations (Note: Was p/n0861782 which is no
longer available. Use p/n 1001141970 CEE 7 Side
Ground Service Kit or p/n 1001141971 CEE 7 Post
Ground Service Kit. Kits includes Box p/n
1001141967 & items 708B, 708E & 708J.)
0861731 1001091973, 1001100331, 1001091974, 1001100333,
1001091975 & 1001100337 Installations
708B 1 Receptacle Options:
See Note 0256202 Installation (Note: Not Available - Purchase
Locally.)
1001141968 1001141971 Service Kit
1001141969 1001141970 Service Kit
4461198 1001091969, 1001100326 Installations
4461201 1001091970, 1001100327 Installations
4461204 1001091971, 1001100328 Installations
4461207 1001091972, 1001100329 Installations
4461244 1001091973, 1001100331 Installations
4461245 1001091974, 1001100333 Installations
4461246 1001091975, 1001100337 Installations
708C 1 Shield, Cover Options:
See Note 0256202 Installation (Note: Not Available - Purchase
Locally.)
Purchase
Receptacle
1001091973,1001091974,1001091975,1001091969,
1001091970,1001091971,1001091972,1001100331,
1001100333,1001100337,1001100326,1001100327,
1001100328 & 1001100329 Installations
708D 1 Connector, Strain Relief Options:
See Note 0256202 Installation (Note: Not Available - Purchase
Locally.)
4460968 1001091969, 1001100326, 1001091970, 1001100327
1001091971, 1001100328, 1001091972, 1001100329
Installations (SN 0300085332 to SN 0300127290)
1001101191 1001091969, 1001100326, 1001091970, 1001100327
1001091971, 1001100328, 1001091972, 1001100329
Installations (SN 0300127290 to SN 0300140000)
4460968 1001091973, 1001091974 & 1001091975 Installations
(SN 0300085332 to SN 0300108684)
4460662 1001091973, 1001100331, 1001091974, 1001100333,
1001091975 & 1001100337 Installations
(SN 0300108684 to SN 0300127290)
1001101191 1001091973, 1001100331, 1001091974, 1001100333,
1001091975 & 1001100337 Installations
(SN 0300127290 to SN 0300140000)
708E 1 Plug, Male Options:
See Note 0256202 Installation (Note: Not Available - Purchase
Locally.)
4461196 1001091969 Installation
4461199 1001091970 Installation
4461202 1001091971, 1001091973 Installations
4461205 1001091972, 1001091974 Installations
4461249 1001091975 Installation
Not Required 1001100326, 1001100327, 1001100328, 1001100329,
1001100331, 1001100333 & 1001100337 Installations
FIGURE 7-4. HARNESS COMPONENTS INSTALLATION (WITH UGM)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
