7-20 800S 860SJ 3121842
SECTION 7 ELECTRICAL
217A 4460465 11 Socket, Female 18 Gauge
217B 4460865 1 Connector - 19 Position
217C 4460509 4 Socket, Female 12 Gauge
217D 4460473 1 Clamp. Cable
217E 4460466 8 Seal, Plug
217F 4460464 11 Pin, Male 18 Gauge
217G 4460508 4 Pin, Male 12 Gauge
218 4922569 1 Harness Assembly - Tower Boom (12/4 - 18/8) 1/A
1060896 20ft/6.1m Cable, Electrical - 12/4&18/8
218A 4460465 22 Socket, Female 18 Gauge
218B 4460865 2 Connector - 19 Position
218C 4460509 8 Socket, Female 12 Gauge
218D 4460473 2 Clamp. Cable
218E 4460466 8 Seal, Plug
219 to 232 Not Used
233 4922660 1 Holding Valve/Lift Dump Harness Assembly (Note: This is
actually two separate harnesses under the same p/n) 2/D
233A 4460880 2 Connector, DIN
233B 4460320 1 Plug, Male - 2 Position
4460226 2 Socket, Female
233C 4460424 1 Connector, Female - 2 Position
4460267 2 Pin, Male
234 Not Used
235 4922871 1 Harness, Limit Switch Upper (To Boom Transport Length
Limit Switch)
Without 7500W Generator
With 7500W Generator
1060902 34ft/10.4m Cable, Electrical - 18/2
4460464 2 Pin, Male
4460897 1 Receptacle, Female - 2 Position
236 4922872 1 Harness, Limit Switch Lower (To Boom Transport Length Limit
Switch)
Without 7500W Generator
With 7500W Generator
1060902 20ft/6m Cable, Electrical - 18/2
4460465 2 Socket, Female
4460891 1 Plug, Male - 2 Position
237 AR Cable, Electrical - 18/2
1061018 AR 800S:
2 Without 7500W Generator (SN 0300085332 to SN
0300103969)
1 Without 7500W Generator (SN 0300103969 to SN
0300140000)
2 With 7500W Generator
1061019 AR 860SJ:
2 Without 7500W Generator (SN 0300085332 to
SN 0300103969)
1 Without 7500W Generator (SN 0300103969 to
SN 0300140000)
2 With 7500W Generator
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (WITHOUT UGM) (SN 0300085332 TO
SN 0300140000)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
