SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121214 – JLG Lift – 6-3
Capacities
Table 6-3. Operating specifications - E300AJP
Capacity: Unrestricted: 500 lbs. (227 kg)
Maximum Travel Grade, stowed
Position (Gradeability) see Figure 4-3. 25%
Maximum Travel Grade, stowed
Position (Side Slope) see Figure 4-3. 5%
Vertical Platform Height 30 ft. (9.14 m
Horizontal Platform Reach
(Up & Over) 20 ft. (6.1 m)
Machine Width 4 ft. (1.22 m)
Turning Radius (Outside) 10 ft. (3.05 m)
Turning Radius (Inside) 5 ft. (1.52 m)
Drive Speed (High Drive)
(Above Horz.) 45-50 sec/ 200ft. (61 m)
55-68 sec/ 50 ft. (15.2 m)
Gross Machine Weight 15,800 lbs. (7167 kg)
Ground Bearing Pressure 130 psi (9.1 kg/cm 2 )
Maximum System Voltage 48 VDC
Maximum Main Relief Hyd. Pressure 3200 psi. (220.6 bars)
Table 6-4. Capacities
Hydraulic Oil Tank 3.0 gallons (11.35 liters)
Hydraulic System (Including Tank) 4.0 gallons (15.14 liters)
Torque Hub, Drive * 17 ounces (0.50 L)
*
Torque hubs should be one half full of lubricant.
