SECTION 2 - PREPARATION AND INSPECTION
3120890 – JLG Lift – 2-9
51. Drive Hub, Left Rear - No visible damage, no evi-
dence of leakage.
52. Drive Motor and Brake, Left Rear - No visible dam-
age, no evidence of leakage.
53. Spindle, Left Rear - Properly secured, no loose or
missing parts, no visible damage. (4 Wheel Steer)
54. Tie Rod and Steering Linkage, Left Rear - No
loose or missing parts, no visible damage. Tie rod
end studs locked. (4 Wheel Steer)
55. Steer Cylinder Assembly, Left Rear - Properly
secured, no visible damage or signs of leakage, evi-
dence of proper lubrication.
56. Frame - No visible damage, no loose or missing
hardware (top and underside).
57. Boom Sections - No visible damage; wear pads
secure. All cylinders - rod end shafts and barrel-end
shafts properly secured.
Figure 2-5. Daily Walk-Around Inspection - Sheet 4 of 4
