SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121264 – JLG Lift – 6-3
Capacities
Tires
Engine Data
Table 6-4. Capacities
Hydraulic Tank 55 gallons (208 liters)
Fuel Tank 31 gallons (117 liters)
Hydraulic System 66 gallons (250 liters)
Table 6-5. Tire Specifications
Size 445/50D710
Load Range J
Ply Rating 18
Load Rating 26,500 lbs. @ 100 psi (12020 kg
@ 6.9 Bar)
Foam Fill Poly urethane HD (55 Durometer)
Foam
Max Tire Load 26,250 lbs. (11,907 kg)
Table 6-6. Deutz TD2011L4 Specifications
Type Liquid Cooled
Number of Cylinders 4
Bore 3.7 in. (94 mm)
Stroke 4.4 in. (112 mm)
Total Displacement 190 cu. in. (3108 cm³)
Compression Ratio 17.5
Firing Order 1-3-4-2
Output 75hp (56 kW)
Oil Capacity
Cooling System
w/Filter
Total Capacity
5 Quarts (4.5 L)
11 Quarts (10.5 L)
16 Quarts (15 L)
Average Fuel Consumption 1.1 gph (4.1 lph)
Idle Engine RPM 1200
Mid Engine RPM 1800
High Engine RPM 2475
