3120687 6-15
S
E
C
T
I
O
N
1
6
H
Y
D
R
A
U
L
I
C
S
SECTION 6 HYDRAULICS
FIGURE 6-4. HYDRAULIC DIAGRAM - STANDARD (S/N 38697 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
2792375 HYDRAULIC DIAGRAM - STANDARD Ref. 1
1 2751013 Hose 4
2 2220472 Fitting, 90° 4
3 2220606 Fitting, Tee 6
4 2220609 Fitting, Reducer 6
5 2750910 Hose 4
6 2230043 Fitting, 90° 4
7 2220473 Fitting, 90° 5
8 2220727 Fitting, Adapter 1
9 2220261 Fitting, Straight 1
10 2220428 Fitting, Quick Disconnect 5
11 2220429 Cap, Dust 5
12 2751852 Hose 2
13 2751111 Hose 2
14 2750897 Hose 1
15 2750896 Hose 1
16 2751432 Hose 1
17 2751433 Hose 1
18 2750908 Hose 2
19 2750990 Hose 2
20 2220371 Fitting, Straight 12
21 2220399 Fitting 2
22 2750785 Hose 2
23 2220582 Fitting, Straight 8
24 2220415 Fitting, Straight 3
25 2220343 Fitting, Straight 5
26 2750762 Hose 1
27 2220600 Fitting, Straight 6
28 2220726 Fitting, 90° 5
29 2750766 Hose 1
30 2220373 Fitting, Straight 6
31 2220238 Fitting, Plug 1
32 2220600 Fitting, Straight 2
33 2750758 Hose 1
34 2751498 Hose 1
35 2220593 Fitting, Straight 1
36 2751483 Hose 1
37 2220385 Fitting, Tee 2
38 4640744 Valve, Check 1
39 2220619 Fitting, Reducer 1
40 2751004 Hose 1
41 2751467 Hose 1
42 2220375 Fitting, Straight 1
43 2720281 Hose, Suction 1
44 1320033 Clamp 4
45 2220376 Fitting, Straight 1
46 2210014 Fitting, 90° 1
47 2751617 Hose 1
