SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121258 – JLG Lift – 6-3
Tires Engine Data
Table 6-4. Tires
Size 265/50 D20 (20" x 9")
Maximum Tire Load 4800 lbs. (2177 kg)
Type Air, Foam-Filled
Size 18" x 7"
Maximum Tire Load 4800 lbs. (2177 kg)
Type Solid
Table 6-5. Kubota D1105-E3
Type Liquid Cooled
Number of Cylinders 3
Bore 3.07 in. (78 mm)
Stroke 3.09 in. (78.4 mm)
Total Displacement 68.5 cu. in. (1123 cm³)
Compression Ratio 24:1
Firing Order 1-2-3
Output 24.8 hp (18.5 kW)
Low Idle RPM 1200 ± 50
High Idle RPM 3000± 50
