SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
7-2 – JLG Lift – 3121618
Dimensional Data
Ground Bearing Pressure - Maximum 119.6 psi (8.41 kg/cm 2 )
Maximum Wind Speed 28 mph (12.5 m/s)
Maximum Manual Force 90 lbs (400N)
Maximum System Voltage 12 volts
Maximum Main Relief Hyd. Pressure 5000 psi (345 Bar)
Table 7-2. Dimensional Data
Turning Radius (Axles Retracted)
Outside
Inside
31 ft. 2.75 in. (9.52 m)
23 ft. 4.25 in. (7.12 m)
Turning Radius (Axles Extended)
Inside
Outside
7 ft. 6.75 in. (2.3 m)
21 ft. 7.75 in. (6.6 m)
Machine Height (stowed) 10 ft. 0.5 in. (3.06 m)
Machine Length (stowed) 47 ft. 9.5 in. (14.57 m)
Machine Length (Transport Position) 63’ 9.5" (19.44 m)
Table 7-1. Operating Specifications
Platform Height (500 lb./230 kg. capacity) 185 ft. 7 in. (56.56 m)
Platform Height (1000 lb./450 kg. capacity) 165 ft. 2 in. (50.34 m)
Horizontal Reach from centerline of rota-
tion
Unrestricted Capacity
Restricted Capacity
80 ft. 0 in. (24.38 m)
68 ft. 11 in. (21.01 m)
Horizontal Reach over end
Unrestricted Capacity
Restricted Capacity
70 ft. 6 in. (21.59 m)
59 ft. 6 in. (18.13 m)
Horizontal Reach over side
Unrestricted Capacity
Restricted Capacity
71 ft. 9 in. (21.86 m)
60 ft. 8 in. (18.49 m)
Overall Width
Axles Retracted
Axles Extended
8 ft. 2 in. (2.48 m)
16 ft. 6.5 in. (5.04 m)
Wheelbase
Axles Retracted
Axles Extended
17 ft. 1.5 in. (5.22 m)
15 ft. 0.5 in. (4.59 m)
Tailswing 7 ft. 7.5 in. (2.32 m)
Ground Clearance (Axle) 9.75 in. (0.25 m)
Table 7-2. Dimensional Data
