Page 356
7-32
SECTION 7 ELECTRICAL
701 cont’d
1001091973
Ref
220V with CEE 7 Post Ground Receptacle & Plug (2x4
Box)
C
1001091971
Ref
220V with CEE 7 Post Ground Receptacle & Plug (70x70
Box)
B
1001091974
Ref
220V with CEE 7 Side Ground Receptacle & Plug (2x4
Box)
C
1001091972
Ref
220V with CEE 7 Side Ground Receptacle & Plug (70x70
Box)
B
Ref
With 2500W Generator:
1001100326
Ref
110V with IEC Yellow Receptacle & Plug
C
1001100327
Ref
220V with IEC Blue Receptacle & Plug
C
1001100337
Ref
220V with AFSINT 107 Keyed Ground Receptacle & Plug
C
1001100331
Ref
220V with CEE 7 Post Ground Receptacle & Plug (2x4
Box)
C
1001100329
Ref
220V with CEE 7 Post Ground Receptacle & Plug (70x70
Box)
C
1001100333
Ref
220V with CEE 7 Side Ground Receptacle & Plug (2x4
Box)
C
1001100328
Ref
220V with CEE 7 Side Ground Receptacle & Plug (70x70
Box)
C
1001093275
Ref
Breaker Box Installation (Required on CE Spec Machines
without Powermite Generator Control Box)
B
1001109863
Ref
Breaker Box Installation (Required on CE Spec Machines
with Powermite Generator Control Box)
A
701A
AR
Box, Switch Options:
0860038
0270022 & 0270024 Installations
0861781
1001091969, 1001091970, 1001100326 & 100110327
Installations
See Note
1001091971,1001091972, 1001100328 & 100110329
Installations (Note: Was p/n 0861782 which is no
longer available. Use p/n 1001100344 CEE 7 Side
Ground Service Kit or p/n 1001100343 CEE 7 Post
Ground Service Kit. Kit include Box p/n
1001141967 & items 701B, 701C & 701D.)
0861731
1001091975, 1001091973, 1001091974, 1001100337
1001100331& 100110333 Installations
1001141967
1001100343, 1001100344, 1001141970 &
1001141971 Kits
701B
1
Receptacle Options:
4460346
0270022 Installation
4460125
0270024 Installation
4461198
1001091969 & 1001100326 Installation (Includes Cvr)
4461201
1001091970 & 1001100327 Installation (Includes Cvr)
Use
1001100343
1001091971 & 1001100328 Installation (Includes Cvr)
(was p/n 4461204)
Use
1001100344
1001091972 & 1001100329 Installation (Includes Cvr)
(was p/n 4461207)
4461244
1001091973 & 1001100331 Installation (Includes Cvr)
4461245
1001091974 & 1001100333 Installation (Includes Cvr)
4461246
1001091975 & 1001100337 Installation (Includes Cvr)
1001141968
1001100343 & 1001141971 Kits
1001141969
1001100344 & 1001141970 Kits
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (MACHINES WITH UGM) (SN
0300069000 TO SN 0300177683) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
