2-84
SECTION 2 TURNTABLE
72
4751600
42
Flatwasher 3/8in Regular
73
4751800
11
Flatwasher 1/2in Regular
74
0760612
4
Capscrew M6 x 25mm
75
0760810
2
Capscrew M8 x 20mm
76
4846821
1
Mount, Motor/Generator
77
4846852
1
Weldment, Engine Tray
78
4922737
1
Harness, Engine Grounding
79
1
Engine, Perkins 404C-22 Options:
All Specs except CE Spec
1001095205
SN 0300096000 to SN 0300135381
1001102131
SN 0300135381 to Present
CE Spec Only
1001095205
SN 0300096000 to Present
80
Not Used
81
3574282
1
Plate, Actuator Mounting
82
Use 1001125978
1
Sensor, Coolant (was p/n 1001097551)
83
Use 1001125978
1
Adapter, Coolant Sensor (was p/n 1001097552)
84
1001097554
1
Sensor, Oil Pressure
85
1
Adapter, Oil Pressure Sensor Options:
1001097555
Adapter (Closest to Block)
70002107
Adapter (Closest to Sensor)
86
1001097588
1
Clip, Tube
87
Not Used
88
3290605
4
Locknut M6
89
1
Nut Options:
3311501
Nut 5/16in-18NC (SN 0300096000 to SN 0300122764)
3290801
M8 x 1.25 (SN 0300122764 to Present)
90 to 92
Not Used
93
4791400
6
Starwasher 1/4in
94
5240600
8
Flatwasher M6 Hardened
95
5240800
2
Flatwasher M8 Hardened
96
1001097553
1
Washer, Coolant Sensor
97
1001097588
1
Clip, Dipstick Tube
98
1001097893
1
Dipstick Assembly
7026885
1
Dipstick
7026886
1
Tube, Dipstick
7026847
2
Washer
7026881
1
O-Ring
99
2
Bolt Options:
0641610
Bolt 3/8in-16NC x 1-1/4in (SN 0300096000 to
SN 0300118775)
0641612
Bolt 3/8in-16NC x 1-1/2in (SN 0300118775 to Present)
100
2
Flatwasher Options:
4751600
Flatwasher 3/8in Regular
4891600
Flatwasher 3/8in Hardened
101
Not Used
102
4831900
1
Lockwasher 8mm (SN 0300125679 to Present Only)
103
1001099926
1
Speed Sensor Kit (Includes Speed Sensor & Connectors)
104
1001099927
1
Actuator Kit (Includes Actuator, Linkage & Connectors)
FIGURE 2-15. PERKINS ENGINE INSTALLATION - WITH ELECTRICAL DRIVEN COOLING FAN
(WITHOUT UGM) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
