SECTION 1 - SPECIFICATIONS
1-2 – JLG Lift – 3120895
1.3 TIRES
1.4 SPECIFICATIONS AND PERFORMANCE
DATA
Table 1-6. GM 3.0L
Fuel Gasoline or Gasoline/LP Gas
No. of Cylinders 4
BHP
Gasoline
LP
83 hp @ 3000 rpm
75 hp @ 3000 rpm
Bore 4.0 in. (101.6 mm)
Stroke 3.6 in. (91.44 mm)
Displacement 181 cu.in. (3.0 L, 2966 cc)
Oil Capacity w/filter 4.5 qts. (4.25 L)
Minimum Oil Pressure
at idle
Hot
6 psi (0.4 Bar) @ 1000 rpm
18 psi (1.2 Bar) @ 2000 rpm
Compression Ratio 9.2:1
Firing Order 1-3-4-2
Max. RPM 2800
Table 1-7. Perkins 404C-22
Fuel Diesel
No. of Cylinders 4
BHP 50 HP (37.3 kW)
Bore 3.3 in. (84 mm)
Stroke 3.9 in. (100 mm)
Firing Order 1-3-4-2
Displacement 135 cu.in. (2.2 L)
Oil Capacity w/filter 10 qt. (9.4 L)
Compression Ratio 23.3:1
Table 1-8. Tires
Size Type Pressure Weight
12x16.5 Pneumatic 90 psi
(6.2 Bar)
128 lbs.
(58 kg)
12x16.5 Foam-filled N/A 328 lbs.
(149kg)
14x17.5 Pneumatic 90 psi
(6 Bar)
128 lbs.
(58 kg)
14x17.5 Foam-filled N/A 440 lbs.
(200kg)
33/16LLx16.1- Sand Pneumatic 90 psi
(2.75 bar)
119.5 lbs.
(54 kg)
33/16LLx16.1- Sand Foam Filled N/A 426 lbs.
(193 kg)
Semitrack Tires
24x12x 12 Pneumatic 20 psi
(1.4 bar)
20.7 lbs.
(9.38 kg)
Table 1-9. Specifications and Performance Data - 400S
Maximum Work Load (Capacity):
Unrestricted:
Restricted:
Optional: standard
500 lbs. (230 kg.)
1000 lbs. (230 kg)
750 lbs. (340 kg)
Maximum Travel Grade, Stowed Position
(Gradeability) 2 W/D-30%
4 W/D-45%
Maximum Travel Grade, Stowed Position
(Side Slope)
5 o
Maximum Vertical Platform Height: 40 ft. (12 m)
Maximum Horizontal Platform Reach: 34 ft. (10 m.)
Turning Radius (Outside) 16 ft. (5 m.)
Turning Radius (Inside) 6 ft.-8 in. (2 m.)
Overall Width 6ft.- 6in. (1.98 m)
Tail swing Zero
Stowed Height 7ft. 4in. (2.24 m)
Stowed Length 20ft. 2in. (6.15 m)
Wheelbase 7ft. 10in. (2,3 m)
Ground Clearance 12in. (30 cm)
Max. Tire Load (400S-500 lbs. Cap.)
Max. Tire Load (400S-750 lbs. Cap.) 6200 lbs. (2812 kg)
8350 lbs. (3788 kg)
Ground Bearing Pressure
12x16.5 FF Tires
14x17.5 pneumatic tires
58 psi (4.07 kg/cm 2 )
45 psi (3.16 kg/cm 2 )
Travel Speed, boom stowed.(2WD/4WD) 4.5 m.p.h. (7.24 kmh)
(27-32 sec/ 200ft.)
Travel Speed, boom elevated. (2WD/4WD) 0.75 m.p.h. (1.20 kmh)
(46-115 sec/ 50 ft.)
Gross Machine Weight Std. 2wd Machine
(Platform Empty, Pneumatic Tires)
500 lb. (230 kg) Capacity
750 lb. (340 kg) Capacity
12,525 lbs. (5681kg)
13,525 lbs. (6135 kg)
Maximum System Voltage 12 VDC
Max. Hydraulic System Operating Pressure 4060 psi (280 bar)
Manual Force 400 N maximum
Maximum Wind Speed 28 mph (12.5 m/s)
