SECTION 1 - BASE
3120876 15AMI 13
ITEM PART NUMBER QTY DESCRIPTION REV
409 4460234 4 Base, Tie-Strap
410 4751000 4 Flatwasher #10 Regular
411 4751400 4 Flatwasher 1/4in Regular
412 4922805 1 Harness, Alarm
413 1001093322 1 Plate, Mounting
414 1001107934 1 Harness, Strobe Light
1001107903 Ref BEACON LIGHT ONLY INSTALLATION (OPTIONAL) A
501 0641406 2 Bolt 1/4in-20NC x 3/4in
502 0721006 2 Screw #10-24NC x 3/4in
503 2920146 1 Strobe Light Assembly
503 7016319 1 Bulb, Flash Tube
503 7016372 1 Replacement Lens
504 3311005 2 Locknut #10-24NC
505 3311405 4 Locknut 1/4in-20NC
506 4240032 AR Tie-Strap
507 4460234 4 Base, Tie-Strap
508 4751000 4 Flatwasher #10 Regular
509 4751400 4 Flatwasher 1/4in Regular
510 1001093322 1 Plate, Mounting
511 1001107934 1 Harness, Strobe Light
