3-8 18RS 3121285
SECTION 3 BOOM
FIGURE 3-2. MAIN BOOM ASSEMBLY
ITEM # PART NUMBER QTY. DESCRIPTION REV.
1001136557 Ref MAIN BOOM ASSEMBLY D
1 0100011 AR Compound, Locking
2 Not Used
3 0761010 8 Bolt M10 x 20mm
4 0962297 2 Bushing
5 1001145202 1 Pin
6 3760133 2 Ring, Retaining
7 4812000 36 Flatwasher M8
8 1001153398 8 Pad, Wear
9 Not Used
10 1001135488 2 Block, Attaching
11 1001135697 1 Boom, Fly
12 1001130688 1 Boom, Base
13 1001136571 6 Shim
14 1001136575 4 Shim
15 1001136583 4 Pad, Wear
16 1001136587 1 Pad, Wear
17 1001136590 4 Shim
18 1001136592 8 Shim
19 Not Used
20 1001138436 3 Shim
21 0701013 6 Bolt M10 x 28mm
22 0701024 4 Bolt M10 x 80mm
23 0761011 18 Bolt M10 x 22mm
24 1001143713 4 Shim
25 Not Used
26 1001150646 1 Telescope Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
27 3900259 4 Bolt 1/2in-13NC x 3/4in
1001136478 Ref POWER TRACK ASSEMBLY D
101 0100011 AR Compound, Locking
102 0760823 3 Bolt M8 x 75mm
103 to 104 Not Used
105 0761032 2 Bolt M10 x 150mm
106 0761009 10 Bolt M10 x 18mm
107 3290605 8 Locknut M6
108 3290805 10 Locknut M8
109 3291005 2 Locknut M10
110 3900364 8 Capscrew M6 x 20mm
111 4811700 16 Flatwasher M6
112 4811900 20 Flatwasher M8
113 4812000 14 Flatwasher M10
114 1001136223 1 Support
