SECTION 3 BOOM
FIGURE 3-1. BOOM AND CYLINDERS INSTALLATION
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
1001134010
Ref
BOOM & CYLINDERS INSTALLATIONS
C
1
0100011
AR
Compound, Locking
2
0100019
AR
Compound, Locking
3 to 4
Not Used
5
0701018
4
Bolt M10 x 50mm
6
0701216
2
Bolt M12 x 40mm
7
0761012
1
Bolt M10 x 25mm
8
0761015
2
Bolt M10 x 35mm
9
0761615
2
Bolt M16 x 40mm
10
Not Used
11
0962297
8
Bushing
12
Not Used
13
3291005
2
Locknut M10
14
3291205
2
Locknut M12
15
Not Used
16
3422578
1
Pin
17
3422582
1
Pin
18 to 20
Not Used
21
3841143
3
Keeper, Pin
22
3841258
2
Keeper, Pin
23
3841287
5
Keeper, Pin
24 to 25
Not Used
26
4812000
4
Flatwasher M10
27
4812100
4
Flatwasher M12
28
Not Used
29
1001130478
1
Master Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
30
1001131748
1
Lift Cylinder Assembly - Main Boom (See CYLINDER SECTION
for Breakdown)
31
1001132163
1
Level (Platform Slave) Cylinder Assembly (See CYLINDER
SECTION for Breakdown)
32
1001132275
1
Platform Rotator Assembly (See PLATFORM ROTATOR
ASSEMBLY for Breakdown)
33
Not Used
34
1001134172
1
Link, Tower
35
1001115672
1
Boom, Tower
36 to 38
Not Used
39
1001136557
1
Main Boom Assembly (See MAIN BOOM ASSEMBLY for
Breakdown)
40
1001137032
2
Screw, Countersunk M10 x 16mm
41
Not Used
42
1001138459
2
Pad, Boom Rest
43
1001138778
1
Pad
44
1001138828
1
Pin
45
Not Used
46
1001138865
1
Pin
47
0762016
5
Bolt M20 x 40mm
48
3422913
1
Pin
49
3423061
5
Pin
