3-4 12SP & 15SP 3120776
SECTION 3 MAST
31 3422717 2 Pin
32 3422750 1 Pin
33 3422752 1 Pin
34 3422757 1 Pin, Keeper
35 2 Pin Cotter Options:
3450304 S/N 0900015116 to S/N 0900018391
See Item 108 S/N 0900018391 to Present
36 3570893 2 Plate (S/N 0900015116 to S/N 0900029975 Only)
37 1 Plate, Clevis Options:
3571101 S/N 0900015116 to S/N 0900018391
See Item 109 S/N 0900018391 to Present
38 1 Plate, Clevis Options:
3571103 S/N 0900015116 to S/N 0900018391
Not Used S/N 0900018391 to Present
39 2 Sheave Assembly Options:
Use 3580286 S/N 0900015116 to S/N 0900016290 (was p/n 3580268)
3580286 S/N 0900016290 to Present
2 Bearing Options: (1 Per Assembly)
0440225 S/N 0900015116 to S/N 0900016290
0440246 S/N 0900016290 to Present
40 3580269 2 Sheave, Sequence Cable
41 2 Chain, Sheave Assembly Options:
3580274 S/N 0900015116 to S/N 0900016290
3580293 S/N 0900016290 to Present
1 Bearing Options: (1 Per Assembly)
0440230 S/N 0900015116 to S/N 0900017527
0440246 S/N 0900017527 to Present
42 3820034 2 Rivet
43 3900187 2 Screw, Shoulder
44 3900192 8 Screw 3/8in-16NC x 1/2in
45 3900205 6 Screw #10-24NC x 5/8in
46 4060960 1 Shield, Mast Cover
47 4060961 1 Shield, Mast Cover
48 4060987 1 Shield, Mast
49 4070860 A/R Shim, Slide Pad
50 4070861 A/R Shim, Slide Pad
51 4070862 A/R Shim, Slide Pad
52 4070970 A/R Shim, Cylinder Mount (S/N 0900015116 to S/N 0900029975
Only)
53 4070971 A/R Shim, Cylinder Mount (S/N 0900015116 to S/N 0900029975
Only)
54 4070988 A/R Shim, Slide Pad
55 4070989 A/R Shim, Slide Pad
56 4070990 A/R Shim, Slide Pad
57 4160124 2 Spring
58 4567491 2 Tube, Spacer
59 4567750 1 Tube, Spacer
60 4567751 1 Tube, Spacer
61 4711400 47 Flatwasher 1/4in Thin
FIGURE 3-1. MAST ASSEMBLY - 12SP WITH 4 SECTION MAST (S/N 0900015116 TO
PRESENT) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
