SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121141 – JLG Lift – 6-3
Chassis
Capacities
Table 6-4. Chassis Specifications
Maximum Travel Grade With boom in stowed
position (Gradeability) 45%
Maximum Travel Grade With boom in stowed
position (Side Slope) 5°
Turning Radius (Axles Retracted)
Outside
Inside
22 ft. 6 in. (6.8 m)
14 ft. 5 in. (4.4 m)
Turning Radius (Axles Extended)
Inside
Outside
8 ft. (2.4 m)
19 ft. 4 in. (5.9 m)
Max Tire Load
1200SJP
1350SJP
25,000 lbs. (11,340 kg)
26,250 lbs. (11,907 kg)
Max Ground Bearing Pressure
1200SJP
1350SJP
100 psi (7.03 kg/cm 2 )
105 psi (7.38 kg/cm 2 )
Maximum Drive Speed 3.25 mph (5.2 kph)
Max. Hydraulic System Pressure 4600 psi (317 Bar)
Maximum Wind Speed 28 mph (12.5 m/s)
Maximum Manual Force 400 N
Electrical System Voltage 12 Volts
Gross Machine Weight (Platform Empty)
1200SJP
1350SJP
41,100 lb. (18,643 kg)
44,750 lb. (20,298 kg)
Table 6-4. Chassis Specifications
Table 6-5. Capacities
Hydraulic Tank 55 gallons (208 liters)
Fuel Tank 31 gallons (117 liters)
Hydraulic System 66 gallons (250 liters)
