Installation
New Brunswick Excella® E-1 Open Air Shaker
English (EN)
13
1. Clamps are installed by securing the base of the clamp to the platform with the correct type and number
of screws.
Eppendorf flask clamps are used on a variety of shaker platforms. Flat head screws of different lengths and
thread pitch are used to secure the clamp. To identify the proper screw for your shaker application by
reference to the head style, consult the following table, find the proper screws, and set the others aside.
4.5 Electrical connections
Before making electrical connections, verify that the power source voltage matches the voltage on the
ELECTRICAL SPECIFICATION PLATE and that the ON/OFF SWITCH is on the OFF position. The
ELECTRICAL SPECIFICATION PLATE and the ON/OFF SWITCH are located on the rear panel (see
Fig. 3-1 on p. 9).
Connect the MAINS/POWER CORD to the MAINS/POWER CONNECTOR on the rear panel and the other
end to a suitable, grounded receptacle.
NOTICE! Damage to shaker
 Do not over fill flasks.
Description Part No. Quantity Application
10 – 24 × 5/16 in (7.9 mm)
flat Phillips head screw
S2116-3051 1 5/16 in (7.9 mm) thick
aluminum, phenolic and
stainless steel platforms.
The previous table also applies to 2800 ml Fernbach Flask Clamps.
CAUTION!
 A detachable main power cord has been provided with your unit. Only use the cord
provided and do not replace cord with an inadequately rated cord.
CAUTION!
 Make sure the speed dial is set to 0 % before turning on the power.
