9
Innova® -86 °C Freezers — Operating manual
Abb. 2: Chest freezer - side and front views
Fig. 2: Chest freezer - side and front views
Abb. 3: U101 freezer - side and front views
Fig. 3: U101 freezer - side and front views
1 Heated vent port 2 Lockable handle
3 Control panel/display 4 Battery switch (alarm) behind lockable panel
5 On/Off circuit breaker behind lockable panel 6 Chart recorder (optional)
7 Quarter turn fasteners 8 Air filter grille
9 Braked castors (front) 10 Specification plate
1 Heated vent port 2 Lockable handle
3 Control panel/display 4 Battery switch (alarm)behind lockable panel
5 On/Off circuit breaker behind lockable panel 6 Chart recorder (optional)
7 Quarter turn fasteners 8 Air filter grille
9 Adjustable feet 10 Specification plate
11 Rear rollers
2 3
10
7
8
9
4
5
6
1
8
4
5
6
1 2
7
3
11 10 9
3
Product description
