4
PCR-Cooler — Instructions for use
3. Insert the tubes or the plate.
The tubes or the plate will not freeze. By changing color from violet to pink or from
dark blue to light blue, the PCR-Cooler shows when the upper temperature value of
7°C has been exceeded. It is also possible to read the temperature of single tubes
by the color of the single bore holes.
Abb. 1:Thermal behavior of a precooled PCR-Cooler and a sample inserted at room temperature
Fig. 1: Thermal behavior of a precooled PCR-Cooler and a sample inserted at room
temperature
4. The PCR-Cooler can be labeled individually using the cards supplied. These cards
are inserted into the slots on the sides of the PCR-Cooler.
60 0 10 –10 120
7°C
22°C
0
5
10
15
20
25
–5
–10
–15
–20
eingebrachte Probe
Temperatur [°C]
Zeit [min]
(Volumen 0,1 mL)
Kühlaggregat
(PCR-Cooler)
