IKA MF 10 basic - Manual (Page 26)

26
In accordance with IKA ® warranty conditions,
the warranty period is 24 months. For claims un-
der the warranty please contact your local dea-
ler. You may also send the machine direct to our
works, enclosing the delivery invoice and giving
reasons for the claim. You will be liable for freight
costs.
Warranty
The warranty does not cover wearing parts, nor
does it apply to faults resulting from improper
use or insuffi cient care and maintenance contra-
ry to the instructions in this operating manual.
Technical data
Design voltage: VAC 230±10%
or VAC 115±10%
Design frequency Hz 50/60
Power input W 1000
Rotor speed rpm 3000 - 6500
Peripheral speed impact grinding m/s 35
Cutting speed cutting grinding m/s 24
Cyclic duration min 120/30
Intermittent operation
Perm. ambient temperature
°C + 5 bis + 40
Perm. relative humidity % 80
Protection class acc. DIN EN 60529 IP 22
Protection at overloaded Current limitation
Fuses on mains plate
230 V A 6,3 Id.-No. 14 080 00
115 V A 12 Id.-No. 26 493 00
Safety Temperature switch on motor,
door limit switch
Protection class I
Overvoltage category II
Contamination level 2
Noise level dbA max. 85
Operation at a terrestrial altitude m max. 2000
Dimensions (WxDxH) mm 310x570x370
Weight kg 10
Subject to technical changes!
