Page 7
TB42/TB50 – 0075251EE
3
Chapter 2 – Specifications
Component Identification
Right Side
Chassis
Lower Controls
Upper Controls
Fuel Tank
Wiring Box
Operator’s
Manual
Steer Wheels
Left Side
Platform
Main Boom
Tip Boom
Hydraulic Fluid Tank
And Filter
Battery Disconnect Switch
Batteries
Engine
Steer Wheels
Platform
Foot Switch
Emergency
Lowering
Valve
Intermediate
Boom
