Chapter 2 – Specifications

6

TB42/TB50 – 0075251EE

General Specifications – TB42/420

Aerial Platform
Working height

14.6 m (48

)

Maximum platform height

12.8 m (42

)

Horizontal reach

10.1 m (33

)

Main boom
Articulation

-18° to +75°

Extension

2.8 m (9

5.7

)

Turntable rotation

360° continuous

Turning radius, inside
Two wheel drive

1.6 m (5

2

)

Four wheel drive

1.7 m (5

6

)

Wheelbase

2.4 m (8

)

Ground clearance

25 cm (10

)

Maximum wheel load

2,654 kg (5,850 lbs)

Maximum ground pressure

3.8 kg/cm² (54 psi)

Weight, EVW approximate
TB42

4,944 kg (10,900 lbs)

TB420

5,987 kg (13,200 lbs)

Stowed width

2.4 m (7

11.5

)

Stowed length

7.2 m (23

6.25

)

Stowed height

2.4 m (7

9.5

)

Platform
Dimensions
Standard steel

76 cm x 152 cm (30

x 60

)

Rated work load

227 kg (500 lb)

Optional steel

76 cm x 234 cm (30

x 92

)

Rated work load

227 kg (500 lb)

Optional aluminum

76 cm x 234 cm (30

x 92

)

Rated work load

227 kg (500 lb)

Optional aluminum

76 cm x 234 cm (30

x 92

)

Rated work load

295 kg (650 lb)

Optional aluminum

76 cm x 152 cm (30

x 60

)

Rated work load

318 kg (700 lb)

Rotation

90° CW to 90° CCW

Maximum number of occupants

2 people

Optional AC generator

220 VAC

Function Speed
Turntable rotation, 360 degrees

100 to 110 seconds

Main boom
Up

40 to 50 seconds

Down

40 to 50 seconds

Extend

40 to 45 seconds

Retract

25 to 30 seconds

Platform rotation, 180 degrees

16 to 20 seconds

Drive
High, booms stowed

4.8 km/h (3.0 mph)

Low, booms elevated

1.6 km/h (1.0 mph)

Drive System
Standard

Four wheel drive

Optional

Two wheel drive

Gradeability

25%

Tires

Street tread, foam filled 10 ply 30 cm x 42 cm (12

x 16.5

)

Bar lug, foam filled 10 ply

30 cm x 42 cm (12

x 16.5

)

Electrical System
Voltage

12 V DC negative chassis ground

Source

Two - 12 V 600 CCA batteries

Fluid recommended

distilled water

Hydraulic System
Maximum pressure

17,237 kPa (2,500 psi)

Reservoir capacity

62.4 l (16.5 US gal)

System capacity

94.6 l (25 US gal)

Maximum operating temperature

93°C (200°F)

Hydraulic fluid recommended
Above -13°C (10°F)

Mobil DTE-13M

(ISO VG32)

Below -13°C (10°F)

Mobil DTE-11M

(ISO VG15)

Engine
Diesel

Cummins B3.3

Diesel

Deutz F3L-2011F

Fuel Tank Capacity
Diesel

75.7 l (20 US gal)

Ambient Air Temperature Operating Range
Celsius

-18°C to 43°C

Fahrenheit

0°F to 110°F

Maximum Wind Speed
Gust or steady

45 km/h (28 mph)

Vibration

less than 2.5 m/sec

2

Sound Threshold

below 97 dB(A)
