Working envelope 3-4, Working envelope, 3-4, Working envelope -4 – Snorkel AB50J User Manual
Page 30: Specifications
page 3 - 6
AB50J – 0163189
3. Specifications
Upper riser boom
Lower riser boom
Jib boom
Serial
number
Front
steering wheels
Rear
drive wheels
Turntable
Ground
controls
Rear lifting
tie down lugs
Chassis
Platform
❑
Left Side View Of Machine
Front
steering wheels
Rear
drive wheels
Chassis
Serial number stamped
on top of chassis tube
Serial number stamped
on left side of chassis
❑
Serial Number Location
