Page 14 107098-022 TM12 - Operation Manual
Labels
L ABELS
These labels shall be present and in good condition before operating the machine. Be sure to read, under-
stand and follow these labels when operating the machine.
HYDRAULIC FLUID
060197-000
Model______________ Serial number:___________
Machine weight _______kg Mfg. date:_________
Maximum wheel load:________
Maximum allowable incline of machine when elevated:_____deg.
Occupants and equipment must not exceed the rated maximum
load:_____kg Maximum platform occupants: _____
Maximum allowable sIde force on platform:_____N
Maximum platform height:______m
Maximum platform reach:______m
Maximum allowable wind speed: ______m/s=Beaufort scale_____
Maximum hydraulic system pressure:_____bar
Maximum system voltage: _______Vdc
This machine is manufactured to comply with
Machinery directive 89-392/CEE
CAUTION: CONSULT OPERATOR'S MANUAL BEFORE USE.
061205-003
030768-001
107052-000
26,3 kg +
014222-903
THIS PLATFORM IS
NOT INSULATED
DIESE ARBEITSBÜHNE
IST NICHT ISOLIERT
CETTE PLATEFORME
N'EST ISOLEE
100102-900
066522-900
INSIDE
INNSEITIG
L'INTERIEUR
107051-900
010076-901
All other uses of the aerial work platform are prohibited!
overhead workplaces (ceilings, cranes, roof structures, buildings etc.).
job. It is designed for repair and assembly jobs and assignments at
intended to lift persons and his tools as well as the material used for the
USE OF THE AERIAL WORK PLATFORM: This aerial work platform is
imperative to keep a safe distance from live parts of electrical equipment!
THIS AERIAL WORK PLATFORM IS NOT INSULATED! For this reason it is
Read operator's manual for more details.
Exceeding the specified permissible maximum load IS PROHIBITED!
or a crane IS PROHIBITED!
The use and operation of the aerial work platform as a lifting tool
Read operator's manual for more details.
NEVER exceed the manual force allowed for this machine.
DISTRIBUTE all platform loads evenly on the platform.
hazards such as holes, drop-offs, bumps, curbs, or debris; and avoiding them.
NEVER operate the machine without first surveying the work area for surface
OPERATE machine only on surfaces capable of supporting wheel loads.
wind rating. Read operator's manual for more details.
NEVER operate the machine when wind speeds exceed this machine's
Move machine to a firm, level surface.
IF ALARM SOUNDS while platform is elevated, STOP, carefully lower platform.
platform onto buildings or other structures, IS PROHIBITED!
Climbing up the railing of the platform, standing on or stepping from the
Always make certain that the swing gate is closed and securely locked!
Dismantling the swing gate or other railing components IS PROHIBITED!
position when the platform is raised!
IT IS PROHIBITED to keep the swing gate or liftable bar in an open
similar devices on the platform IS PROHIBITED!
To extend the height or the range by placing of ladders, scaffolds or
blocking elevating assembly.
NEVER perform service on machine while platform is elevated without
cables or hoses before using.
hardware, hydraulic leaks, loose wire connections, and damaged
INSPECT the machine thoroughly for cracked welds, loose or missing
VERIFY that all labels are in place and legible before using.
damaged or missing labels.
NEVER use a machine that is damaged, not functioning properly, or has
the persons on the aerial work platform and in its working range.
To bypass any safety equipment IS PROHIBITED and presents a danger for
emit explosive hydrogen gas.
NEVER charge batteries near sparks or open flame. Charging batteries
at the approval by UpRight.
Modifications to the aerial work platform are prohibited or permissible only
the keyswitch off and removing key.
AFTER USE, secure the work platform from unauthorized use by turning
deactivate all powered functions.
IN CASE OF EMERGENCY push emergency stop switch to
1 060197-000
2 101210-000
3 061205-003
5 005223-909
6 030768-001
7 107050-900
9 107052-000
11 010076-901
12 065568-901
15 062562-951
16 067195-002
19 014222-903
20 100102-900
21 066522-900
22 068635-001
23 101208-001
24 107051-900
25 107053-000
