Introduction
Page 3 Operation Manual
I
NTRODUCTION
This manual covers all models of the TM12 Aerial Work Platform. This manual must be stored on the
machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G
ENERAL
D
ESCRIPTION
Figure 1: TM12 Series
1. Platform
W A R N I N G ! !
DO NOT use the maintenance platform
without guardrails properly assembled and
in place
2. Entry Bar
3. Elevating Mast
4. Platform Controls
5. Manual Case
6. Electrical Box
7. Hydraulic Reservoir
8. Level Sensor (inside Door)
9. Battery Tray
10. Emergency Lowering Valve
11. Battery Charger
12. Drive Relief Valve
13. Charger Outlet Plug
4
6
7
8
9
12
11
13
1
2
3
5
10
