Operating Dimensions
Maximum Working Height 12.20 m
Maximum Cage Height 10.20 m
Maximum Outreach 5.00 m
Outrigger Footprint (manual) 3.6 m x 3.6 m
Outrigger Footprint (hydraulic) 3.7 m x 3.7 m
Cage Dimensions
Length 1.20 m
Width 0.80 m
Guard-rail Height 1.10 m
Toe-board Height 0.15 m
Travel Dimensions
Towing Length 5.30 m
Closed Width 1.5 m
Closed Height 2.2 m
Weight (manual outriggers) 1300 kg
Operating Parameters
Safe Working Load 215 kg
Maximum Horizontal Pull 400 N
Maximum Wind Speed 12.5 ms -1
Rotation 360 °
BUSHES Acetol resin polymer with sintered
bronze base (DX)
PIVOT PINS EN 3B high tensile steel
TYRES 165 X 13 8ply
TYRE PRESSURE 3.8 Bar (55psi) cold
WHEEL NUTS TORQUE SETTING 100Nm (75Lbft)
BATTERIES 2 X 6v 225Ah (Heavy duty traction)
CHARGER 12vdc 25a – 110 OR 220Vac 50Hz
TECHNICAL SPECIFICATION
Maximum Chassis Inclination 0.5 °
Vibration Less than 2.5ms
Operating Temperature Range -20°c to +40°c
-2
3
