Specifications
S2646E/S3246E – 1370385 21
General Specifications – S3246E
Aerial Platform
Working height 11.58 m (38′)
Maximum platform height 9.75 m (32′)
Turning radius
Inside 25.4 cm (10″)
Outside 2.5 m (101″)
Wheelbase 1.9 m (75″)
Ground clearance
Pothole protector raised 10.1 cm (4″)
Pothole protector lowered 2.5 cm (1″)
Maximum wheel load 1328 kg (2,928 lbs)
Maximum ground pressure 13.8 kg/cm² (196 psi)
Weight, EVW
Approximate 3003 kg (6,620 lbs)
Stowed width 116.8 cm (46″)
Stowed length 254 cm (100″)
Stowed height
Guardrails raised 251.4 cm (99″)
Guardrails lowered 182.8 cm (72″)
Platform
Dimensions
Main 114.3 cm x 238.7 cm (45″ x 94″)
Extension 104.1 cm x 91.4 cm (41″ x 36″)
Total length with extension 330.2 cm (130″)
Rated work load
Total 317.5 kg (700 lb)
Extension 113.3 kg (250 lb)
Maximum number of occupants
Outside 1 person
Inside 2 people
Function Speed
Platform raise 40 to 50 seconds
Platform lower 50 to 60 seconds
High drive
Platform lower than 2.1 to 2.4 m (7 to 8 feet)
3.2 km/h (0 to 2 mph)
Low drive
Platform higher than 2.1 to 2.4 m (7 to 8 feet)
0.8 km/h (0 to 0.5 mph)
Drive System
Standard Two wheel drive
Gradeability 25%
Maximum drive height 9.75 m (32′)
Drive/Lift Level Sensor Interlock
Side-to-side 2 degrees
Front-to-rear 4 degrees
Tires
Nonmarking solid rubber 40.6 cm x 12.7 cm (16″ x 5″)
Electrical System
Voltage 24 V DC negative chassis ground
Source Four - 6 V 240 amp hour batteries
Fluid recommended distilled water
Charger 40 amp
Hydraulic System
Maximum pressure 21,373.75 kPa (3,100 psi)
Reservoir capacity 34 l (9 US gal)
System capacity 35 l (9.25 US gal)
Maximum operating temperature 71°C (160°F)
Hydraulic fluid recommended
Above -13°C (10°F) Mobil DTE-13M (ISO VG32)
Below -13°C (10°F) Mobil DTE-11M (ISO VG15)
Ambient Air Temperature Operating Range
Celsius -18°C to 43°C
Fahrenheit 0°F to 110°F
Maximum Wind Speed
Gust or steady 12.5 m/s (28 mph)
Vibration less than 2.5 m/sec²
Sound Pressure Level
At work station below 70 dB(A)
