ITEM
Platform Size (Inside min.)
Standard w/Deck
Optional w/o Deck
Maximum Platform Capacity (Distributed)
Standard w/Deck
Optional w/o Deck
Maximum Number of Occupants
Standard w/Deck
Optional w/o Deck
Height
Working Height
Maximum Platform Height
Minimum Platform Height
Dimensions
Weight
Overall Width
Overall Height (Lowered)
Overall Length (Deck in)
Driveable Height
Surface Speed
Platform Lowered
Platform Raised
Energy Source
System Voltage
Battery Charger
Battery Duty Cycle
Hydraulic Tank Capacity
Maximum Hydraulic System Pressure
Lift System
Drive Control
Control System
Horizontal Drive
Tires
Parking Brakes
Turning Radius
Maximum Gradeability
Wheel Base
Guardrails
Toeboard
MX15
22.5 in. x 98.5 in. (.57 m x 2.5 m)
26 in. x 62 in. (.66 m x 1.57 m)
550 lbs. (250 kg)
660 lbs. (300 kg)
Two people, only one person on Deck
Two people
20 ft. 9 in. (6.32 m)
14 ft. 9 in. (4.5 m)
36.2 in. (920 mm)
1,962 lbs. (890 kg)
30 in. (760 mm)
76 in. (1.93 m)
63 in. (1.60 m)
14 ft. 9 in. (4.5 m)
2.75 mph (4.43 km/h)
.75 mph (1.2 km/h)
24V battery pack (4-220 ampere hour, 6 Volt
batteries, min. wt. 62 lbs (28.12 kg) each), 4 HP
DC electric motor
24 VDC
20 AMP, 120 VAC 60 Hz, Automatic
25% for 8 Hours
3.4 gal (12.9 L)
2500 psi (172 Bar)
One Single Stage Lift Cylinder
Proportional
Proportional Joystick Controller with Interlock
Lever, Footswitch, Toggle Selector Switch, and
Red Mushroom Emergency Stop Switch
Dual Front Wheel
12 in. (30.5 cm) diameter solid rubber,
Non-marking
Dual, Spring Applied, Hydraulic Release
1 in. (25 mm) Inside
25% (14°)
48.5 in. (1.23 m)
39 in. (1.02 m) or 43.5 in. (1.10 m)
6 in. (152 mm)
MX19
22.5 in. x 98.5 in. (.57 m x 2.5 m)
26 in. x 62 in. (.66 m x 1.57 m)
500 lbs. (225 kg)
550 lbs. (250 kg)
Two people, only one person on Deck
Two people
25 ft. (7.62 m)
19 ft. (5.8 m)
40.15 in. (1020 mm)
2,160 lbs. (980 kg)
30 in. (760 mm)
80 in. (2.03 m)
63 in. (1.60 m)
19 ft. (5.8 m)
2.75 mph (4.43 km/h)
.75 mph (1.2 km/h)
24V battery pack (4-220 ampere hour, 6 Volt
batteries, min. wt. 62 lbs (28.12 kg) each), 4 HP
DC electric motor
24 VDC
20 AMP, 120 VAC 60 Hz, Automatic
25% for 8 Hours
3.4 gal (12.9 L)
2700 psi (186 Bar)
One Single Stage Lift Cylinder
Proportional
Proportional Joystick Controller with Interlock
Lever, Footswitch, Toggle Selector Switch, and
Red Mushroom Emergency Stop Switch
Dual Front Wheel
12 in. (30.5 cm) diameter solid rubber,
Non-marking
Dual, Spring Applied, Hydraulic Release
1 in. (25 mm) Inside
25% (14°)
48.5 in. (1.23 m)
39 in. (1.02 m) or 43.5 in. (1.10 m)
6 in. (152 mm)
FOR MORE INFORMATION
Local Distributor:
USA
TEL: (800) 926-5438 or (559) 662-3900
FAX: (559) 673-6184
801 S. Pine St., Madera, CA 93637
060570-002
06-02
Specifications*
* Specifications subject to change without notice.
Safety Rules and Operating Instructions
Safety Rules and Operating Instructions
Meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1990
Refer to Service Manual for complete parts and service information.
