Page 3 Operation Manual
INTRODUCTION
This manual covers all models of the M1230E Aerial Work Platform. This manual must be stored on the
machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
GENERAL DESCRIPTION
Figure 1: M1230E Series
Introduction
4
6
7
8
9
12
11
13
1
2
3
5
10
! !
W A R N I N G
DO NOT use the maintenance
platform without guardrails properly
assembled and in place
1. Platform
2. Entry Gates
3. Elevating Mast
4. Platform Controls
5. Manual Case
6. Chassis Controls
7. Hydraulic Reservoir
8. Power / Control Module, Inc level
sensor (EZ230)
9. Battery Tray
10. Emergency Lowering Valve
11. Battery Charger
12. Drive Relief Valve
13. Charger Outlet Plug
