Introduction & Specifications
Section
1.2 Specifications
Table 1-1: Specifications
1.2
ITEM METRIC IMPERIAL (ANSI)
Duty Cycle 45% of 8 hour shift 45% of 8 hour shift
Platform Size 0.7 m x 1.3 m (inside gaurdrails) 2.3 ft x 4.3 ft (inside gaurdrails)
Max. Platform Capacity 215 kg 475 lbs
2 People 2 People
Min. Platform Floor Height
13.45 m
11.45 m
0.65 m
44.12 ft
37.56 ft
2.13ft
6.10 m 20.00 ft
Platform Height At
Maximum Outreach
5.40 m 17.72 ft
Stowed Dimensions
Length
Width
Height
4.04 m
1.50 m
2.00 m
13.25 ft
4.92 ft
6.56 ft
Ground Clearance 0.13 m 0.43 ft
Wheel Base x Gauge 2.00 m x 1.27 m 6.56 ft x 4.16 ft
Rotation 362 degrees non-continuous 362 degrees non-continuous
3,770 kg 7,826 lbs
3,970 kg 8,840 lbs
Drive Speed Stowed 0 - 4 km/h 0 - 2.49 mph
Drive Speed Elevated 0 - 0.72 km/h 0 - 0.45 mph
Maximum Gradeability 36% 36%
Inside Turning Radius 0.40 m 1.31 ft
Outside Turning Radius 2.40 m 7.87 ft
Power Source 48V DC 4kW, 8 X 6V 220Ah Batteries 48V DC 5.4HP, 8 X 6V 220Ah Batteries
System Voltage 48V 48V
Battery Charger 48V 25A 220/110VAC 50/60 Hz 48V 25A 220/110VAC 50/60 Hz
25 Litres 6.5 Gallons US
Max. Hydraulic Pressure 145 bar 2105 psi
ISO #46 ISO #46
2 Double Acting Lift Cylinders With
Lock Valves And Manual Emergency
Lowering Facility.
1 Double ActingTelescopic Cylinder
2 Double Acting Lift Cylinders With
Lock Valves And Manual Emergency
Lowering Facility.
1 Double ActingTelescopic Cylinder
Refer to Section 5 of the Service &
Parts Manual
Refer to Section 5 of the Service &
Parts Manual
Control System
One handed Proportional Joystick
Operating Energy Efficient Motor
Control System (MOS90)
One handed Proportional Joystick
Operating Energy Efficient Motor
Control System (MOS90)
Wheels/Tyres
400 mm Diameter Steel Disc Wheel
With Solid All Surface Tyres
15.75 inch Diameter Steel Disc Wheel
With Solid All Surface Tyres
Braking
Automatic Spring Applied
Hydraulic Release
Automatic Spring Applied
Hydraulic Release
69.5 dB(A) 69.5 dB(A)
Indoors
Outdoors
1 Person 2 People
Unloaded Weight
With Load/ Max Weight
Max Noise Level
Page 14 Operation Manual
