Introduction
Operation Manual Page 3
I
NTRODUCTION
This manual covers the AB38N and the AB38W Aerial Work Platforms.
This manual must be stored on the machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G
ENERAL
D
ESCRIPTION
W A R N I N G ! !
DO NOT use the maintenance platform without guardrails properly assembled and in place.
Figure 1: AB38
1. Platform
2. Entry Bar
3. Elevating Assembly
4. Platform Controls
5. Manual Case
6. Lower Controls
7. Hydraulic Reservoir
8. Level Sensor
9. Batteries
10. Emergency Lowering Valves
11. Battery Charger
1
2
3
4
5
6
7
8
9
10
10
11
