9
e p y T
y r e v il e D r e v o h c t i w s
e r u s s e r p e r u s s e r p w o l e r u s s e r p h g i h
- . . P n i m / l 4 , 4 n i m / l 4 , 1
a P M 6 1
- . . G n i m / l 7 , 4 n i m / l 5 4 , 1
14 Technical data
* Weight without oil filling
14.1 Delivery
14.2 Noise emission
82 dB(A) 72 dB(A)
following the regulations horizontal measuring distance 1,0 [m] 5,0 [m]
of EN ISO 3744: measuring distance above the
upper edge of the power pack
1,0 [m] 1,0 [m]
14.3 Others
Temperature range:
Ambient temperature (power pack in operation)
-24 ... +45 [°C]
Storage temperature (power pack not in operation) -30 ... +60 [°C]
15 Trouble Shooting
Malfunction No delivery or only partial delivery from pump at no load.
Cause Air in the suction area of the pump.
Remedy Reduce the pressure at no load as far as possible - turn the adjusting screw of
the pressure limiting valve in anti-clockwise direction. Switchíng the pump on/off
repeatedly supports the venting process.
Type Ref. no. Type Ref. no. Oil capacity Usable oil cap.
Motor
Weight*
500 bar 84112/ 700 bar 84112/ standard-max. standard-max. ca. kg
PO6-1E-10-50 5607 5601 7.5 l 6 l Electric motor 34
PO6-2E-10-50 5608 5602 -- -- 230 V/50 Hz, 1,5 kW 36.5
PO6-1D-10-50 5609 5603 9 l 7.5 l electr. protection acc. 35
PO6-2E-25-50 5628 5622
15 l - 24 l 10 l - 19 l
to DIN EN 60034-5 43
PO6-1D-25-50 5629
-..-70
5623 IP 54 41.5
GO6-1E-10-50 5610 5604 7.5 l 6 l
4-stroke gasoline
31
GO6-2E-10-50 5611 5605 -- --
engine
33,5
GO6-1D-10-50 5612 5606 9 l 7.5 l
2.6 kW
32
GO6-2E-25-50 5631 5625
15 l - 24 l 10 l - 19 l 3200 min -1
38
GO6-1D-25-50 5632 5626 36.5
