22
9.3 Operating and storage temperature ranges
9.2 Control unit CU 4 DVV
Device type CU 4DVV Value Units Remarks
Item number 70-20-20
Dimensions l x w x h 1310 x 640 x 1112 mm set up
51.6 x 25.2 x 43.8 in.
Dimensions l x w x h 1215 x 640 x 450 mm folded
47.8 x 25.2 x 17.7 in.
Operating pressure max. 53 MPa
7700 psi
Control valve Lifting 4 Number
Control valve traversing/lifting 2 Number
Control valve Locking/lifting 2 Number
Hydraulic
connections NW 06 quick-
disconnect-
coupling
Ambient
temperature -20 … +55 °C
-4 … 131 °F
Weight 68 kg
150 lbs.
Specifi cation of
hydraulic fl uid HM 10 ISO 6743-4
Operating temperature [°C] / [°F] -20 … +55 -4 … +131
Environmental
temperature (device in
operation)
[°C] / [°F] -25 … +45 -13 … +113
Storage temperature
(device not in operation)
[°C] / [°F] -30 … +60 -22 … +140
