15
15 Technical data
* 1MPa = 10 bar
1 Necessary oil quantity in the hydraulic power pack for operating the tool
(Difference in quantity piston / rode side)
15.1 Cutting performance / cutting forces
The cutting performance is indicated for perfect condition of the blades (new or perfectly
reground), central bolts tightened in accordance with the specifications and correct
handling (see Section 9) of the devices.
15.2 Central bolt / Torque
15.3 Oil recommendations
For LUKAS hydraulic devices, use mineral oil in accordance with DIN 51 524 and others
Recommended viscosity range: 10 ... 200 mm²/s,
delivered with HLP 22 to DIN 51 524
Max. Schneidgut-Abmessungen
Type of Form of Strength LS 501 EN LS 511 EN LS 530 EN
material material
Rm (N/mm 2 )
550 (500) Ш 35 Ш 37 Ш 35
Steel
400 Ш 37 Ш 40 Ш 37
Type LS 501 EN / LS 511 EN / LS 530 EN
Central bolt M 27 x 1,5
Torque (Nm) 130+10
Range of oil temperature Viscosity rating Remarks
A - 24 ... + 30 °C HL 5
B - 18 ... + 50 °C HLP 10
C - 8 ... + 75 °C HLP 22
D + 5 ... + 80 °C HLP 32
E - 8 ... + 70 °C HF - E 15 biodegradable
Type LS 501 EN LS 511 EN LS 530 EN
Ref. no. 84150/1231 84150/1211 84150/1236
Dimensioons l x w x h without
connection hoses (mm)
772x245x170 740x255x170 775x235x165
Opening at the tips (mm) 180 150 283
Weight incl. oil filling (kg) 19,3 18,8 17,9
Operating pressure (MPa) * max. 63*
Necessary oil quantity (l) 1 0,15 0,15 0,15
DIN EN 13204 BC 180H-19 BC 150H-19 CC 200H-18
