RVF1231ST
www.ruvati.com Printed in USA
1-855-4-RUVATI
Page 5
®
7. Unscrew both screws of the hose
weight until it is in two pieces. Place
one half of the hose weight on the
center sections of the spray hose.
Then place the remaining half of the
weight against the other half and re-
insert the screws. Do not tighten the
screws completely yet (Figure 5).
8. Attach the spray hose to the spray
hose connection hose by screwing
it in with an adjustable wrench or
pliers.
9. Make sure the spray hose weight is
vertical on the loosest section of the
spray hose and tighten the screws
with a Phillips-head Screwdriver to
secure it into place (Figure 6).
6. Attach the hot and cold water sup-
ply hoses to the faucet by threading
them up through the threaded shank
and screwing the end of the hose into
the hole of the faucet body (Figure
4).
Figure 5
Figure 4
Figure 6
