MBW F46/4 User Manual
Page 28
- 25 -
ITEM
PART NO.
DESCRIPTION
QTY
1.
01250
GROOVE PIN
1
2.
01253
GRIP
2
3.
01278
PULLEY
1
4.
05357
CLEVIS
1
5.
05395
PIVOT PIN
1
6.
05398
SAFETY SWITCH ASSEMBLY
1
7.
05477
SWIVEL
1
8.
07592
SPLICE TERMINAL
1
9.
07774
SHORTING WIRE ASM
1
10.
11742
HANDLE BAR
1
11.
16040
COMPRESSING SPRING
1
12.
16047
SELF TAP SCREW, 1/4-20 x 1/2
2
13.
16075
HANDLE
1
14.
16078
CLIP BEARING
2
15.
16079
CAM, ACTIVATING
1
16.
16081
LEVER ARM
1
17.
16083
LOCK DOG
1
18.
16084
TRIGGER PULL
1
19.
16086
SHAFT, ACTIVATING
1
20.
16087
CABLE
1
21.
16099
DOWEL PIN, 3/16 x 5
1
22.
16370
SPRINGBOX
1
23.
16372
COVER
1
24.
16373
CABLE CLEVIS
1
25.
16374
CONSTANT FORCE SPRING
1
26.
16375
BEARING SPOOL
1
27.
20306
THROTTLE ASM
1
28.
F0312SP
SPIROL PIN, 3/6 x 1-1/2
3
29.
F042003PMS
PHMS, 1/4-20 x 3/8 ZP
2
30.
F042004FWS
FWLS, 1/4-20 x 1/2
4
31.
F042006HCS
HHCS, 1/4-20 x 3/4 GR5 ZP
4
32.
F0420DLN
DEFORMED LOCKNUT, 1/4-20
2
33.
F0420ELN
ELASTIC LOCKNUT, 1/4-20
2
34.
F04LW
LOCKWASHER, 1/4
2
35.
F04PW
WASHER, 1/4
4
36.
F0518ELN
ELASTIC LOCKNUT, 5/16-18
1
37.
F0518HN
HEX NUT, 5/16-18
1
38.
F061622HCS
HHCS, 3/8 x 2-3/4 GR5 ZP
2
39.
F061644HCS
HHCS, 3/8-16 x 5-1/2 GR5 ZP
1
40.
F0616DLN
DEFORMED LOCKNUT, 3/8
3
41.
F06SW
WASHER, 3/8
6
42.
F08SW
WASHER
1
43.
F091238HCS
HHCS, 9/16-12 x 4-3/4 GR5 ZP
1
44.
F0912ELN
ELASTIC LOCKNUT, 9/16-12
1
REPLACEMENT PARTS
16080
LEVER ARM ASSEMBLY (includes 11, 16-18 & 21)
1
16092
HANDLE ASSEMBLY (includes all above items)
1
16367
SPRING SPOOL ASSEMBLY (includes 24-26, 29 & 32)
1
20306
THROTTLE ASSEMBLY
1
